120A MPPT Solar Inverter 4200Watt Hybrid Inverter OFF-Grid System 24Vdc High PV input voltage range(90~450VDC) Dual Output Solar System
120A MPPT Solar Inverter 4200Watt Hybrid Inverter OFF-Grid System 24Vdc High PV input voltage range(90~450VDC) Dual Output Solar System
Couldn't load pickup availability
The Future Green Power In OFFOF, this product has three models 3.6KW-4.2KW-6.2KW, tested in various countries, easy to install, simple in appearance, stable in operation, touch screen buttons, RGB lamps to show different working modes, 3.6KW and 4.2KW are for 24Vdc battery system, 6.2KW is for 48Vdc battery system, which can meet different needs of users. used for 48Vdc battery system, which can meet different needs of users. Supports battery-less operation and built-in 120A MPPT charging to maximize power. High range of PV input from 90V~450V.support Dual output.
Products Key Features:
▲Pure sine wave solar inverter(on/off Grid)
▲WIFI&GPRS available for IOS and Android (Options)
▲Inverter can run without battery
▲One-key restoration to factory Settings
▲Built-in Lithium battery automatic activation
▲Built-in 120A(for 3.6KW/6.2KW)
▲MPPT:Max 6200W(for 3.6KW),max 6500W(for 6.2KW)solar charge
▲High PV input voltage range(90~450VDC)
▲Built-in anti-dust kit for harsh environment
▲Smart battery charge design to optimize battery life
▲Dual Output
Before Order:
1.All Message will get reply within 24 hours.
2.Products is Already on Frankfurt Warehouse.
3.Free User Manual And Tech Support.
4.After Payment will send out within 24 Hours
Packing List:
1 * MPPT-ECO-4.2KW / MPPT-ECO-6.2KW (By Your Choice)
1 *User Manual(In English)
Products Specification
|
Model
|
MPPT-ECO-3.6KW PLUS |
MPPT-ECO-6.2KW PLUS |
|
Phase |
1-Phase |
|
|
Maximum PV Input Power |
6200W |
6500W |
|
Rated Output Power |
3600W/3600VA |
6200W/6200VA |
|
Maximum Solar Charging Current |
120A |
|
|
GRID-TIE OPERATION |
||
|
PV Input(DC) |
|
|
|
Nominal DC Voltage/Maximum DC Voltage |
360VDC/500VDC |
|
|
Start-up Voltage/Initial Feeding Voltage |
90VDC/120VDC |
|
|
MPPT Voltage Range |
90~450VDC |
|
|
Number of MPPT/Max Input Current |
1/23A |
|
|
GRID OUTPUT(AC) |
|
|
|
Norminal Output Voltage |
220/230/240VAC |
|
|
Output Valtage Range |
195.5~253VAC |
|
|
Norminal Output Current |
15.7A |
27.0A |
|
Power Factor |
>0.99 |
|
|
Feed-in Grid Frequency Range |
49~51±1Hz |
|
|
EFFICIENCY |
|
|
|
Max Conversion Efficiency(Solar to AC) |
98% |
|
|
TWO LOAD OUTPUT POWER(V2.0) |
|
|
|
Full Load |
3600W |
6200W |
|
Maximum Main Load |
3600W |
6200W |
|
Max Second Load(battery mode) |
1200W |
2067W |
|
Main Load Cut Off Voltage |
22VDC |
44VDC |
|
Main Load Return Voltage |
26VDC |
52VDC |
|
OFF-GRID OPERATION |
|
|
|
AC Input |
||
|
AC Start-up Voltage/Auto Restart Voltage |
120-140VAC/180VAC |
|
|
Acceptable Input Voltage Range |
90-280VAC or 170-280VAC |
|
|
Maximum AC Input Current |
30A |
40A |
|
Nominal operating frequency |
50/60Hz |
|
|
Surge power |
7200W |
12400W |
|
BATTERY MODE OUTPUT(AC) |
|
|
|
Nominal Output Voltage |
220/230/240VAC |
|
|
Output Waveform |
Pure sine wave |
|
|
Efficiency(DC to AC) |
94% |
|
|
BATTERY&CHARGER |
|
|
|
Nominal DC Voltage |
24VDC |
48VDC |
|
Maximum Solar Charging Current |
120A |
|
|
Maximum AC Charging Current |
100A |
|
|
GENERAL |
|
|
|
PHYSICAL |
|
|
|
Dimension,D*W*H(mm) |
110*334*423 |
|
|
Net Weight(Kgs) |
9 |
10 |
|
INTERFACE |
|
|
|
Communication Port |
RS232/WIFI/GPRS |
|
|
ENVIRONMENT |
|
|
|
Operating Temperature |
-10~50℃ |
|
