Solar Cables MC4 Steck 10/20/50/100/200 Pairs Male Female Solar Cable Connectors for DIY Solar Panel 1000V Solar System
Solar Cables MC4 Steck 10/20/50/100/200 Pairs Male Female Solar Cable Connectors for DIY Solar Panel 1000V Solar System
Regular price
$9.99 USD
Regular price
$14.99 USD
Sale price
$9.99 USD
Unit price
per
Tax included.
Couldn't load pickup availability
Features:
- Protection Class:2
- Rated Current:30A
- Protection Degree:IP2X,unmated;IP67,mated
- Quick & simple assembly processing and simple removal of plugs without the aid of any extra instrument
- MC4 Solar Panel Cable Connectors (MC4 Male and MC4 Female) Double seal rings for better waterproof effect
- Compatible with PV cables with different insulation diameters
- Resistance of extra high & low temperature and fireproof
- Load capability with big current and high voltage
Details:
- Protection Class:2
- Withstanding Voltage:1000 V DC
- Rated Current:30A
- Contact Resistance:Less than 0.5 Mohms
Specification:
- Insulation Material:PC/PA, black
- Temperature Range: -40~85℃
- Contact Material: Copper, Sliver plated
- Flame Class: UL94-V0
- Rated Current: 30A
- Suitable cable: 2.5mm², 4mm², 6mm² (AWG14, AWG12, AWG10)
- Pin dimension: 4.0mm²
- Contact resistance: ≤0.5mmΩ
- Waterproof degree: IP67
- Safety Class: Ⅱ
- Insulation Material: PC/PA, black
Package included:
- 1 Pair Connectors
